![Lamello Cabineo 8 M6 black [2000pcs]](/product-images/IMG_FOT_MAK_Cabineo-CNC__SALL__AIN__V2.jpg/2574649000091521232/300x300 "Lamello Cabineo 8 M6 black [2000pcs]")
Lamello Cabineo 8 M6 black [2000pcs]
₹65,000.00 ₹81,250.00
Warranty
Not Applicable Country of origin
Switzerland GST Extra
18% Available on Request
| Technical Specifications — Lamello Cabineo 8 | |
|---|---|
| Installation tolerance longitudinal | ± 0.1 mm |
| Installation tolerance radial | ± 0 mm |
| Minimum workpiece width | 21 mm |
| Minimum material thickness for edge cuts | 12 mm |
| Minimum material thickness for surface cuts | 9 mm |
| Minimum material thickness for centre wall machining | 16 mm |
| Tensile strength in particle board | 520 N |
| Tensile strength in MDF | 610 N |
| Tensile strength in beech | 1530 N |
| Shear strength in particle board | 530 N |
| Shear strength in MDF | 680 N |
| Shear strength in beech | 1430 N |
| Size (LxWxH) | 33.8 x 10.8 x 16.5 mm |
| Screw length | 8 mm (black wood screw) |
| Housing material | Fiberglass reinforced plastic |
| Required drill | Ø 15 mm hole (or Ø 12 mm cutter) + Ø 5 mm screw hole |
TEST
Lamello Cabineo 8 — Inspiration & Application
 |
| FEATURE — ADVANTAGE — BENEFIT | ||
|---|---|---|
| Feature / Fact | Advantage (So what?) | Benefit (You get / You save) |
| QUALITY | ||
| Shorter screw version of Cabineo designed... | Shorter screw version of Cabineo designed for centre/dividing panel connections. | Delivers Swiss-engineered Lamello performance on every cut. |
| Allows centre wall connections in 16... | Allows centre wall connections in 16 mm panels (vs 24 mm for Cabineo 12). | Delivers Swiss-engineered Lamello performance on every cut. |
| One-piece, pre-installed connector — no loose... | One-piece, pre-installed connector. | no loose parts during assembly. |
| Assembled with cordless drill and Cabineo... | Assembled with cordless drill and Cabineo bit. | Delivers Swiss-engineered Lamello performance on every cut. |
| Available in white or black housing... | Available in white or black housing with optional cover caps. | Delivers Swiss-engineered Lamello performance on every cut. |
| PRODUCTIVITY | ||
| Same housing as Cabineo 12 —... | Same housing as Cabineo 12. | identical machining across all workpieces. |
| Pure surface machining — no edge... | Pure surface machining. | no edge drilling required, compatible with all CNC machines. |
