Name: Nanxing CNC 6-Sided Drilling Machine ND612DTSL with feeding conveyor systems
Brand: Nanxing
SKU: NXG-ND612DTSL-CS
Price: 5850000.0 INR
Availability: OutOfStock

Nanxing CNC 6-Sided Drilling Machine ND612DTSL with feeding conveyor systems

FEATURES

Long clamp beam & fast clamps 5.5m longer high-rigidity clamp
Feed-in & out table
Positioning Side aligner & Support / press plates
Board length, width detector
6 slots tool changer
Tool setting gauge
5.5kw+3.5kw main spindle
Top drilling block 1 boring blocks 2.2kw,
Optimized drilling blocks layout +saw blade
2 boring blocks 2.2kw with Vertical drills: 19+19
Independent grooving saw 1.7kw; Saw blade size:Ф100*Ф22*δ4 fixed in X direction.
Bottom drilling block 1.6kw 9 vertical drills
Min. processing Panel length: 200-3000mm / Panel width 30-1200mm
Stack processing
Side Grooving
Machine is configured with Lamello aggregate & tool
Anti-handling device for infeed table
3No. Dust collection port
Hand controller
Control system
Windows 10 operating system
Control interface is modern and friendly
Manual programming interface
Simulation function
Easy tools setting
Statistics function
Bar-code reader
File format support (MPR, DXF, BAN, BPP, PDX; XML; XX)
Side routing-One head aggregate
Board thickness sensor
Air jet for Grippe
A-02 Conveyor BCC3015 1No.
A-03 Controlling System 1No.
A-04 -. Auto Scanner 1No.

Available on Request

₹5,850,000.00

₹7,312,500.00

Customize

TEST

Boring Machine

Nanxing CNC 6-Sided Drilling Machine ND612DTSL with feeding conveyor systems

Multi-spindle boring precision. Every hole, every time.

QUICK SPECS

32 mm

Pitch

5–35 mm

Drill Dia

12 mo / 2000 hr

Warranty

HOW IT WORKS

Load Board

Align Stops

Drill Holes

Check Pitch

Stack Output

KEY FEATURES

— Long clamp beam & fast clamps 5.5m longer high-rigidity clamp

— Feed-in & out table

— Positioning Side aligner & Support / press plates

— Board length, width detector

— 6 slots tool changer

— Tool setting gauge

— 5.5kw+3.5kw main spindle

— Top drilling block 1 boring blocks 2.2kw,

— Optimized drilling blocks layout +saw blade

— 2 boring blocks 2.2kw with Vertical drills: 19+19

FEATURE	ADVANTAGE	BENEFIT TO YOU
SAFETY
CE-certified safety design	Meets international safety standards	You get a machine built for operator safety
Emergency stop circuit	Instant power cut-off on activation	You get immediate halt in emergencies
Enclosed moving parts	Reduces contact with rotating components	You get a safer working environment
QUALITY
Precision-engineered components	Tight tolerances on all machined parts	You get accurate, consistent output every shift
Rigid steel frame construction	Eliminates vibration during operation	You get cleaner cuts and better surface finish
Quality control sensors	Auto-detects deviation in real time	You get fewer rejects and less rework
USER FRIENDLY
Tool-free adjustment	No spanners needed for size changes	You get faster changeovers and less idle time
PRODUCTIVITY
High-speed processing capability	More parts per shift than manual methods	You get significantly higher daily output
Fast changeover design	Quick size and program changes	You get more productive hours per working day
Reliable cycle-time consistency	Same output rate shift after shift	You get predictable delivery schedules for customers
ROI
Reduced labour dependency	One operator can run the machine alone	You save on staffing costs and wage bills
Lower material waste	Precision cuts reduce offcut losses	You save on raw material spend every month
Durable long-life components	Extended service intervals	You save on spare parts and maintenance costs
TRUST
Authorised Nanxing Distributor	Direct factory support and genuine parts	You get the real machine with full manufacturer backing
caple.in — In business since 1974	50+ years of woodworking machinery expertise	You get advice from engineers who know the trade
12-month / 2000-hour warranty	Whichever comes first — no ambiguity	You get protected investment from day one
Trained service team	Factory-trained engineers for installation and support	You get fast, knowledgeable on-site support
Pan-India support network	Service coverage across India with multiple demo centres	You get local support wherever your factory is

TECHNICAL SPECIFICATIONS
Min. processing Panel length	200-3000mm / Panel width 30-1200mm

FREQUENTLY ASKED QUESTIONS

What is the minimum pitch between drill holes?

The standard pitch is 32 mm to match the European cabinet system. Some models support variable pitch — check the spec table above.

How many spindles does this machine have?

Refer to the spindle count in the Quick Specs section above. Multi-spindle models allow simultaneous vertical and horizontal drilling.

Can I drill both faces of a panel in one pass?

Some models support double-sided drilling. Refer to the product name and specification table to confirm this capability.

What board dimensions can the machine handle?

Refer to the panel size range listed in the Quick Specs and Technical Specifications sections above.

What is the warranty period?

12 months or 2000 operating hours, whichever comes first.

Where can I find the full manual and spare parts list for the ND612DTSL?

Full documentation for the ND612DTSL is available through caple.in. Contact our team or book a demo to receive the technical manual and parts catalogue.

What air pressure/CFM does the ND612DTSL require?

The ND612DTSL requires an air supply at 6 bar with approximately 15 CFM continuous consumption. Ensure your compressor and drier can deliver this reliably.

What is the total power consumption of the ND612DTSL?

The ND612DTSL draws approximately 7.4 HP (5.5 kW) total power. Use a 16-amp 3-phase 415V supply with separate earthing and a 10 KVA stabiliser for safe operation.

What dust extraction capacity is needed for the ND612DTSL?

The ND612DTSL needs approximately 1,766 CFM (3,000 CMH) dust extraction through standard dust ports. We recommend the Dust Collector AXC 3HP | 3000-3500 CMH.

What is the weight of the ND612DTSL?

The ND612DTSL weighs Not specified — contact sales. Ensure floor load capacity and proper foundation before installation.

What is under the customer’s scope?

Travel, food and stay for service engineers; material handling and lifting equipment; power tools and consumables for machine foundation; operator safety equipment; basic electrical connections up to the machine; general tool kit and measuring instruments — are all under the customer’s scope.
