Hydraulic Cold Press CH40410-100TT [1250x3000, 100T, 1300mm, 5.5kW]
₹750,000.00 ₹937,500.00
Warranty
12 Months GST Extra
18% Available on Request
TECHNICAL DATA
• Name Model : 3 X 1.25m trip1.3m
• Max higher : 3.4m
• Pressing plate size : 1250 X 3000
• Number of Cylinder : 4pcs
• Pressure : 100T
• Opening distance : 1300m
• Thickness of pressing plate : 900mm
• Installed power : 5.5kw
• Overall dimensions : 3400 X 1250mm
• Power supply : 415V 3PH 50 HZ.
• Net weight : @3T - 8 bolt for cyl lock
• Bottom and top need make it full cover by steel
• Side need use the steel road and need the bearing type for lifting - 300mm bottom thickness/190mm top platen - 15 mm plate thickness Excluded Hydraulic Oil
