TECHNICAL SPECIFICATIONS:
Vacuum table, 4 zones
- 1300*2500*200mm
- Richauto DSP A11 controller
- HQD 6KW air-cooling spindle
- Folinn 7.5KW Inverter
- Leadshine 750W servo motor and driver
- Oubang planetry reducer
- Golden bridge 5.5KW vacuum pump
- Taiwan HIWIN 25/25/25 squire rails
- PCRCH 1.5M helical rack on XY axis
- Taiwan 2505 TBI ball screw on Z axis
- Manual lubrication
- Frech Schneider electrical components
- Autonics/Omron Limited switch
- 380V/3Ph/50Hz
Available on Request
₹550,000.00
₹687,500.00
