Ferro Tiger Slim Lift E Shape

For Edge Banding Machine Feeding/Receiving Application TECHNICAL SPECIFICATIONS - Number of Scissors Arms : One - Max Capacity of lift table : 2000 Kgs - Load to Raise : 2000 Kgs - Load to Lower : 2000 Kgs - Top Platform Size : 1400 mm x 1350 mm ? E Shape - Max height from base frame : 900 mm - Closed height : 100 mm - Stroke / Travelling lift : 800 mm - Motor : 3HP - 3 Phase 415 V AC 50 Hz. - Power Source : 3PH, 415V + Neutral - Control Voltage : 24V DC - Control type : Pedal Switch - Top Platform base sheet : 5 mm thick MS sheet - Power pack position : Outside of scissor lift - Movement / Location : Stationary-Floor Mounted - Equipment Color : RAL 5017 (Racing Blue) OPERATIONAL SPECIFICATIONS - Lifting time / Speed : 32s approximate @ 25mm/s - Lowering time / Speed : 32s approximate @ 25mm/s ? Adjustable - Cycle Time : Customer to specify - Frequency of Operations per hour : Customer to specify - Duty Cycle ? No. of Shifts : Customer to Specify - Motor Running Type : Non-Continuous - Circuit Type ? for raising and lowering : Inching - Stopping Accuracy : +/- 5mm - Site temperature Max & Min : NA - Humidity : NA
