| Milling & Slotting |
High-Speed Milling Unit
200 mm diameter cutter, 4 KW, 3000 r/min | Pre-mills the board edge before banding — removes chipping, taper, and inconsistent edge profile left by the panel saw cut. | - You get a clean, flat edge surface before glue is applied.
- You achieve stronger banding adhesion — no gaps from an uneven substrate edge.
- You save rework and rejected panels from poor edge preparation.
|
Adjustable Slotting Unit
Slot height 3–23 mm, power 0.35 KW | Cuts a precise groove for T-mould or PVC slot-in banding profiles, matching a wide range of panel thicknesses in one machine. | - You get flexibility to run multiple banding profiles on the same line.
- You achieve consistent slot depth without manual re-tooling between jobs.
|
| Gluing & Banding |
3000 ml Glue Pot (PUR or EVA)
Dual glue-type compatible reservoir | Runs either PUR (moisture-cure, higher bond strength, heat/water resistant) or EVA (fast-set, economical) depending on the job — no machine changeover required. | - You save on glue cost by switching to EVA for standard indoor furniture runs.
- You achieve premium bond strength with PUR for kitchen, bath, or export-grade panels.
- You get one machine covering both budget and premium production lines.
|
4+4 Pressing Roller Bank
0.25 KW banding drive | Eight rollers apply progressive, even pressure along the full banding pass — bonding the strip firmly along the entire panel length, not just at the ends. | - You get a tight, bubble-free bond across the whole edge length.
- You reduce edge lifting and delamination complaints from customers.
- You achieve consistent finish quality even at 12 m/min feed speed.
|
| Finishing — Cutting, Trimming, Scraping & Polishing |
Automatic End Cutting
0.37 kW end-cutting unit | Trims the banding strip flush at the panel's leading and trailing edges automatically, in-line, without a separate manual cutting step. | - You save labour — no manual trimming station required after banding.
- You get clean, square corners ready for the next process.
|
Top & Bottom Trimming Unit
0.75 kW trimming power | Trims excess banding strip flush with the panel face on both the top and bottom edges in the same pass. | - You get a flush, furniture-grade finish without a second handling step.
- You achieve higher throughput vs. hand-trimming each panel.
|
Both-Side Scraping
Dual scraping stations | Removes any remaining glue squeeze-out or trimming residue from both faces of the banded edge before polishing. | - You get a smooth, glue-free edge surface every time.
- You reduce customer complaints about sticky or rough edges.
|
Dual Polishing Motors
0.37 kW polishing power | Buffs the finished banded edge to a smooth, presentable gloss, matching the finish quality expected on retail-ready furniture. | - You get showroom-ready panels straight off the line.
- You achieve a consistent premium look across every batch.
|
| Utilities & Line Efficiency |
3-Point Dust Extraction
φ100 mm × 3 extraction ports | Collects dust and chips directly at the milling, trimming, and scraping stations as they are generated, rather than letting them accumulate on the line. | - You get a cleaner shop floor and safer working environment.
- You save on manual cleanup time between shifts.
- You reduce contamination risk on the finished panel surface.
|
Continuous 12 m/min Feed
Single-pass, straight-line processing | One panel pass covers milling, slotting, gluing, banding, cutting, trimming, scraping, and polishing — with no manual transfer between stations. | - You save labour — one operator can run the full line.
- You achieve significantly higher daily output vs. manual/semi-automatic banding.
- You reduce handling damage from moving panels between separate machines.
|
