Nanxing Sliding Table Saw MJ1138F (415V) [3800mm Table | 1200mm Rip-cut Fence | 6.6 Kw]

₹500,000.00 ₹625,000.00
Warranty
12 Months
Country of origin
China
GST Extra
18%
Available on Request

TECHNICAL DATA

• Max. Cutting length length : 3700mm

• Ripping capacity : 1200mm

• Cutting thickness at 0 / 45 Deg. : 70/100mm

• Main saw Speed : 3800/5200rpm

• Main saw Motor : 5.5kw

• Scoring saw Speed : 9000rpm

• Scoring saw Motor : 1.1kw

• Saw blade tilting Deg. : 0-45°

• Dust collection: Dia. : 120mm

• Total power: : 6.6kw

• Dimension: : 3300×3370×1200mm

• Net weight: : 785kg

• Voltage : 415V 3Ph 50Hz

TEST

Panel Saw

Nanxing Sliding Table Saw MJ1138F (415V) [3800mm Table | 1200mm Rip-cut Fence | 6.6 Kw]

Accurate panel cutting. Fast throughput. Clean results.

QUICK SPECS

3300 x 3370 mm

Work Area

6.6kw - Dimension: : 3300×3370×1200mm - Net weight: : 785kg - Voltage : 415V 3Ph 50Hz

Total Power

6.6kw

Power

5200

Speed

785kg

Weight

415V 3Ph 50Hz

Power Supply

HOW IT WORKS

01

Load Panel

02

Set Fence

03

Rip Cut

04

Cross Cut

05

Stack Parts

KEY FEATURES
— TECHNICAL DATA:
— Max. Cutting length length : 3700mm
— Cutting thickness at 0 / 45 Deg. : 70/100mm
— Saw blade tilting Deg. : 0-45°
— Dust collection: Dia. : 120mm
— Total power: : 6.6kw
— Dimension: : 3300×3370×1200mm
— Net weight: : 785kg
FEATUREADVANTAGEBENEFIT TO YOU
SAFETY
CE-certified safety designMeets international safety standardsYou get a machine built for operator safety
Emergency stop circuitInstant power cut-off on activationYou get immediate halt in emergencies
Enclosed moving partsReduces contact with rotating componentsYou get a safer working environment
QUALITY
Precision-engineered componentsTight tolerances on all machined partsYou get accurate, consistent output every shift
Rigid steel frame constructionEliminates vibration during operationYou get cleaner cuts and better surface finish
Quality control sensorsAuto-detects deviation in real timeYou get fewer rejects and less rework
USER FRIENDLY
Simple control interfaceEasy-to-read display and controlsYou get quick operator training and confident use
Centralized lubrication pointsAll grease points in one locationYou get faster, easier routine maintenance
Clear diagnostic displaysOn-screen error codes and guidanceYou get quick fault identification and resolution
PRODUCTIVITY
High feed speed (5200)More panels processed per hourYou get higher daily output from the same shift
Reliable cycle-time consistencySame output rate shift after shiftYou get predictable delivery schedules for customers
ROI
Reduced labour dependencyOne operator can run the machine aloneYou save on staffing costs and wage bills
Lower material wastePrecision cuts reduce offcut lossesYou save on raw material spend every month
Durable long-life componentsExtended service intervalsYou save on spare parts and maintenance costs
TRUST
Authorised Nanxing DistributorDirect factory support and genuine partsYou get the real machine with full manufacturer backing
caple.in — In business since 197450+ years of woodworking machinery expertiseYou get advice from engineers who know the trade
12-month / 2000-hour warrantyWhichever comes first — no ambiguityYou get protected investment from day one
Trained service teamFactory-trained engineers for installation and supportYou get fast, knowledgeable on-site support
Pan-India support networkService coverage across India with multiple demo centresYou get local support wherever your factory is
TECHNICAL SPECIFICATIONS
Max. Cutting length length3700mm
Ripping capacity1200mm
Cutting thickness at 0 / 45 Deg.70/100mm
Main saw Speed3800/5200rpm
Main saw Motor5.5kw
Scoring saw Speed9000rpm
Scoring saw Motor1.1kw
Saw blade tilting Deg.0-45°
Dust collectionDia. : 120mm
Total power: 6.6kw
Dimension: 3300×3370×1200mm
Net weight: 785kg
Voltage415V 3Ph 50Hz
FREQUENTLY ASKED QUESTIONS
What panel sizes can this saw cut?
The machine handles standard sheet sizes up to the dimensions listed in the Quick Specs above.
Can I make both rip cuts and cross cuts?
Yes, the machine supports both rip and cross-cut operations. Some models also include a scoring blade for chip-free cuts.
What blade size does this machine use?
Refer to the Technical Specifications table above for the blade diameter specification.
Is a single operator sufficient to run this machine?
Yes, with proper setup the machine can be operated by one person. Material handling aids (roller tables) are recommended for large panels.
What is the cut depth capacity?
See the Technical Specifications section above for the maximum depth of cut.
Where can I find the full manual and spare parts list for the MJ1138F?
Full documentation for the MJ1138F is available through caple.in. Contact our team or book a demo to receive the technical manual and parts catalogue.

What air pressure/CFM does the Nanxing Sliding Table Saw MJ1138F (415V) [3800mm Table | 1200mm Rip-cut Fence | 6.6 Kw] require?

The Nanxing Sliding Table Saw MJ1138F (415V) [3800mm T requires an air supply at 6 bar with approximately 15 CFM continuous consumption. Ensure your compressor and drier can deliver this reliably.

What is the total power consumption of the Nanxing Sliding Table Saw MJ1138F (415V) [3800mm Table | 1200mm Rip-cut Fence | 6.6 Kw]?

The Nanxing Sliding Table Saw MJ1138F (415V) [3800mm T draws approximately 8.9 HP (6.6 kW) total power. Use a 16-amp 3-phase 415V supply with separate earthing and a 10 KVA stabiliser for safe operation.

What dust extraction capacity is needed for the Nanxing Sliding Table Saw MJ1138F (415V) [3800mm Table | 1200mm Rip-cut Fence | 6.6 Kw]?

The Nanxing Sliding Table Saw MJ1138F (415V) [3800mm T needs approximately 3,237 CFM (5,500 CMH) dust extraction through standard dust ports. We recommend the Dust Collector AXC 5HP | 4500-5000 CMH.

What is the weight of the Nanxing Sliding Table Saw MJ1138F (415V) [3800mm Table | 1200mm Rip-cut Fence | 6.6 Kw]?

The Nanxing Sliding Table Saw MJ1138F (415V) [3800mm Table | 1200mm Rip-cut Fence | 6.6 Kw] weighs 785kg. Ensure floor load capacity and proper foundation before installation.

What is under the customer’s scope?

Travel, food and stay for service engineers; material handling and lifting equipment; power tools and consumables for machine foundation; operator safety equipment; basic electrical connections up to the machine; general tool kit and measuring instruments — are all under the customer’s scope.
