Lamello Tenso P-14
Lamello Tenso P-14

Lamello Tenso P-14

Technical Specifications — Lamello Tenso P-14
Installation tolerance longitudinal± 1 mm
Installation tolerance radial± 1 mm
Minimum workpiece width75 mm
Minimum material thickness for edge cuts12 mm
Minimum material thickness for surface cuts11 mm
Minimum material thickness for centre wall machining19 mm
Minimum material thickness for angle bisector18 mm
P-System groove depth (P-System setting)P-14
Clamping forceapprox. 35 lbs per connector (155 N)
Size (LxWxH)66 x 27 x 9.7 mm
StrengthDepending on the adhesive
MaterialFiberglass reinforced plastic
Groove depth14 mm
CutterØ 100.4 × 7 × 22 mm
₹64.00
