FEATURES
• Long clamp beam & fast clamps – 3.3 m
• Infeed air float table – 500 × 1613 mm
• Feed-out table – 500 × 1613 mm
• Positioning system
• Accurate movement of each axis (X, Y, U) transported by inclined rack and pinion
• Auto greasing
• Board length detector
• Processing unit
• Quick-change tool
• Cable chain
• Minimum processing size
• Stack processing
• Hand controller
• Start button & pedal switch
• E-stop & pause bar
• Industrial computer
• Control system
• Excellent electrical components
• Bar-code reader
• User-friendly operation
• File format support
• Air conditioner on control cabinet
• Air jet for gripper
• Board thickness sensor
Technical Data
• Total Power: 13.87 kW
• Machine Size: 3962 × 2222 × 2271 mm
• Power Supply: 415 V / 50 Hz
• Air Supply: 0.6–0.7 MPa
• Control System: SYNTEC
• Panel Length: 200–3,000 mm
• Panel Width: 30–1,000 mm
• Panel Thickness: 10–60 mm
• Max. Travelling Speed – X/U axis: 135 m/min
• Max. Travelling Speed – Y axis: 75 m/min
• Max. Travelling Speed – Z axis: 30 m/min
• Max. Travelling Speed – V axis: 30 m/min
• Working Table Material: HPL
• Working Table Size: 1232 × 275 mm
• Working Table Height: 955 mm
• Drilling Block Qty: Top 1 + Bottom 1
• Vertical Drills Qty (Top): 10
• Horizontal Drills Qty (Top): X: 6 + Y: 4
• Vertical Drills Qty (Bottom): 9
• Max. Drill Diameter: Φ35 mm
• Drill Spacing: 32 mm
• Drill Rotation Speed: 5000 rpm
• Shank Diameter: Φ10 mm
• Drill Length: 70 mm
• Main Spindle: 1 × 3.5 kW (Top)
• Dust Collector Qty: 2
• Dust Collector Diameter: Top 200 mm × 1 + Bottom 125 mm × 1
• Dust Collector Speed: ≥28 m/min
Available on Request
₹2,300,000.00
₹2,875,000.00
