• FEATURES 1. Sanding belt oscillation controlled by photocell sensor. 2. Microcomputer controlled thickness setting. 3. Automatic control for conveyor belt tracking. 4. Front and rear head equipped with chrome plated pressure plate & rubber covered pressure roller. 5. Leveling adjustment for sanding drum and pressure device. 6. Independent start control for main motor. 7. Automatic 2
• Step startinging on main motor. 8. Motor overload protection. 9. Emergency Stop Device -- Sanding belt break or mistrack. Power failure. Main Motor overload. 10. Variable feed speed 11. The conveyor belt is Heavy Duty type. 12. The machine body is made by all steel, not be wired by H iron.
TECHNICAl DATA
• Main Motor: 40.30 HP Feed Motor: 5 HP Table Hoist Motor: 1 HP Sanding Belt: 52" x 75" Panel Cleaning Brush Roller 1 Set Air Jet Sanding Belt Cleaning Device 2 Set
