Material Handling Equipment

• SPECIFICATION:- Model  : Mobile Slim Lift (Skid Lift)

• Battery Operated- Lifting capacity  : 1000 Kgs- Fork length  : 1200 mm- Overall width over fork  : 685 mm- Height of the fork lowered  : 90 mm- Travelling Lift  : 810 mm- Maximum stacking height  : 900 mm- Power Pack  : 2 KW, 12V DC Motor with 1.6 CC Pump- Battery Charger  : SPE Italian Make, 12V, 15A- Power Source  : 12V 200 Amp Tubular battery- Frame  : Heavy duty formed steel for continuous use"- Steering  : Skid Lift is capable of turning through 180°, with minimum turning radius for easymaneuverability."- Wheels / Fork Rollers  : 200 x 50 mm dia PU Castor Wheels with Lock / 80 x 60 mm dia PU Rollers- Linear Movement  : Manual- Movement : With Auto Raising & Lowering Arrangement

• SPECIFICATION:

• Number of Scissors Arms : One

• Max Capacity of lift table : 1000 Kgs

• Load to Raise/Lower : 1000 Kgs

• Top Platform size : 2200 mm x 800 mm

• Max height from base frame : 900 mm

• Closed height : 300 mm (With Conveyor Rollers)

• Stroke / Travelling lift : 600 mm

• Motor : 1.5 HP - 3 Phase 415 V AC 50 Hz.

• Power Source : 3 PH, 415V Neutral

• Control Voltage : 220 V AC

• Control type : Foot Operated Pedal Switch

• Top Platform base sheet : 5 mm thick MS Sheet

• Power Pack Position : Inside of Scissor Lift

• Movement / Location : Stationary – Floor Mounted

• Equipment Color : RAL 7035 White

• Roller Conveyor Diameter : Ø 50 mm

• Roller Pitch & Length : As per our design

• Conveyor Roller Make : Reputed Make

• Conveyor Type : Gravity Rollers

• Senzor : Auto Raising & Auto Lowering

• Lifting time / Speed : 15 sec approximate @ 40 mm/sec

• Lowering time / Speed : 15 sec approximate @ 40 mm/sec

• Cycle Time : Customer to specify

• Frequency of Operations per hour : Customer to specify

• Duty Cycle – No. of Shifts : Customer to specify

• Motor Running Type : Non-Continuous

• Circuit Type – for raising and lowering : Inching

• Stopping Accuracy : /- 10 mm

• Site temperature Max & Min : N/A

• Humidity : N/A

• SPECIFICATIONS Model Number : LH 100 3E 90 22 15 2TCapacity : 2000 kgsPlatform Size: 2200 x 1500 mmMax height : 900 mmMin height : 100 mmStroke : 800 mmMotor : 3 HPControl Voltage : 24 V DCAuto Raising / Lowering Sensor

• Capacity: 2000 Kgs. Fork L x W: 1800 x 685mm Lift Ht.: 195mm Fork Lowered Ht. 85mm With Tandem Nylon Wheels Paint Finish: Powder Coated in Melon Yellow Shade.
