TECHNICAl DATA

• Model : BY214X10/16(2)H1RC

• Total pressure : 1600KN

• Specific pressure : 3.8Kgf/cm2

• Working layer : 2 layers

• Platen No.& Size : 3-3200X1300X42mm(solid steel drilled hot platen covered with mylar)

• Platen opening : 170mm

• Cylinder No.& Dia : 10-φ85mm

• Max temperature : 120℃

• Heating way : Electric heating with thermal oil

• Heating medium : thermal oil

• Installation power : 4 1.5 54KW

• Platen opening way : Automatically

• Loading way : Length side,Manually

• Voltage : 3PE 415V 50Hz

TECHNICAL DATA

• Model : BY214X9/16(3)H1RC

• Total pressure : 1600KN

• Specific pressure : 4.1Kgf/cm2

• Working layer : 3

• Platen No.& Size : 4-3000x1300x42mm(solid steel drilled hot platen covered with mylar)

• Platen opening : 120mm

• Cylinder No.& Dia : 10-φ85mm

• Max temperature : 120℃

• Heating way : Electric heating with thermic oil

• Heating medium : Thermic oil

• Installation power : 77.5KW

• Platen opening way : Automatically

• Loading way : Length side,Manually

• Voltage : 3PE 415V 50Hz

TECHNICAL DATA

• Total pressure : 1600KN

• Specific pressure: : 4.1Kgf/cm2

• Working layer : 2

• Platen No.& Size : 3-3000x1300x42mm(solid steel drilled hot platen covered with mylar)

• Platen opening : 170mm

• Cylinder No.& Dia : 10-φ85mm

• Max temperature : 120℃

• Heating way : Electric heating with thermic oil

• Heating medium: : Thermic oil

• Installation power : 4 1.5 54KW

• Platen opening way : Automatically

• Loading way : Length side,Manually

• Voltage : 3PE 415V 50Hz

TECHNICAL DATA

• Total pressure : 1600KN

• Specific pressure: : 4.1Kgf/cm2

• Working layer : 1

• Platen No.& Size : 2-3000x1300x42mm(solid steel drilled hot platen covered with mylar)

• Platen opening : 360mm

• Cylinder No.& Dia : 10-φ85mm

• Max temperature : 120℃

• Heating way : Electric heating with thermic oil

• Heating medium: : Thermic oil

• Installation power : 4 0.75 36KW

• Platen opening way : Automatically

• Loading way : Length side,Manually

• Voltage : 3PE 415V 50Hz

TECHNICAl DATA

• Total pressure : 1600KN

• Specific pressure : 5gf/cm2

• Working layer : 2 layers

• Platen No.& Size : 3-2500x1300x42mm(solid steel drilled hot platen covered with mylar)

• Platen opening : 170mm

• Cylinder No.& Dia : 10-φ85mm

• Max temperature : 120℃

• Heating way : Electric heating with thermal oil

• Heating medium : thermal oil

• Installation power : 4 0.75 36KW

• Platen opening way : Automatically

• Loading way : Length side,Manually

• Voltage : 3PE 415V 50Hz

TECHNICAL DATA

• Total pressure : 1000KN

• Specific pressure : 3.1gf/cm2

• Working layer : 3 layers

• Platen No.& Size : 4-2500x1300x42mm(solid steel drilled hot platen covered with mylar)

• Platen opening : 120mm

• Cylinder No.& Dia : 6-φ85mm

• Max temperature : 120℃

• Heating way : Electric heating with thermal oil

• Heating medium : thermal oil

• Installation power : (4 0.75 48)KW

• Platen opening way : Automatically

• Loading way : Length side,Manually

• Voltage : 3PE 415V 50Hz

TECHNICAl DATA

• Model : BY214×8/16(1)H1RC

• Total pressure : 1600KN

• Specific pressure : 5gf/cm2

• Working layer : 1 layers

• Platen No.& Size : 2-2500x1300x42mm(solid steel drilled hot platen covered with mylar)

• Platen opening : 360mm

• Cylinder No.& Dia : 10-φ85mm

• Max temperature : 120℃

• Heating way : Electric heating with thermal oil

• Heating medium : thermal oil

• Installation power : 28.75KW

• Platen opening way : Automatically

• Loading way : Length side,Manually

• Voltage : 3PE 380V 50Hz

TECHNICAL DATA

• Total pressure : 1600KN

• Specific pressure : 5gf/cm2

• Working layer : 3 layers

• Platen No.& Size : 4-2500x1300x42mm(solid steel drilled hot platen covered with mylar)

• Platen opening : 120mm

• Cylinder No.& Dia : 10-φ85mm

• Max temperature : 120℃

• Heating way : Electric heating with thermal oil

• Heating medium : thermal oil

• Installation power : 4 0.75 48KW

• Platen opening way : Automatically

• Loading way : Length side,Manually

• Voltage : 3PE 415V 50Hz

TECHNICAl DATA

• Model : BY214×10/16(3)H1RC

• Total pressure : 1600KN

• Specific pressure : 4.3Kgf/cm2

• Working layer : 3 layers

• Platen No.& Size : 4-3200x1300x42mm(solid steel drilled hot platen covered with mylar)

• Platen opening : 120mm

• Cylinder No.& Dia : 10-φ85mm

• Max temperature : 120℃

• Heating way : Electric heating with thermal oil

• Heating medium: : thermal oil

• Installation power : (4 1.5 72KW ) 77.5KW

• Platen opening way : Automatically

• Loading way : Length side,Manually

• Voltage : 3PE 415V 50Hz

• Packing : Bare but properly secured

• Gross Weight : About 10000.00 kg

TECHNICAl DATA

• Model : BY214×10/16(1)H1RC

• Total pressure : 1600KN

• Specific pressure : 3.8Kgf/cm2

• Working layer : 1 layers

• Platen No.& Size : 2-3200x1300x42mm(solid steel drilled hot platen covered with mylar)

• Platen opening : 360mm

• Cylinder No.& Dia : 10-φ85mm

• Max temperature : 120℃

• Heating way : Electric heating with thermal oil

• Heating medium : thermal oil

• Installation power : 4 0.75 36KW

• Platen opening way : Automatically

• Loading way : Length side,Manually

• Voltage : 3PE 415V 50Hz

TECHNICAL DATA

• Model : BY214×8/10(2)H1RC

• Total pressure : 1000KN

• Specific pressure : 3.1gf/cm2

• Working layer : 2 layers

• Platen No.& Size : 3-2500x1300x42mm(solid steel drilled hot platen covered with mylar)

• Platen opening : 170mm

• Cylinder No.& Dia : 6-φ85mm

• Max temperature : 120℃

• Heating way : Electric heating with thermal oil

• Heating medium : thermal oil

• Installation power : (4 0.75 36)KW

• Platen opening way : Automatically

• Loading way : Length side,Manually

• Voltage : 3PE 415V 50Hz

TECHNICAL DATA

• Total pressure : 1000KN

• Specific pressure : 3.1gf/cm2

• Working layer : 1 layers

• Platen No.& Size : 2-2500x1300x42mm(solid steel drilled hot platen covered with mylar)

• Platen opening : 360mm

• Cylinder No.& Dia : 6-φ85mm

• Max temperature : 120℃

• Heating way : Electric heating with thermal oil

• Heating medium : thermal oil

• Installation power : (4 0.75 24)KW

• Platen opening way : Automatically

• Loading way : Length side,Manually

• Voltage : 3PE 415V 50Hz
