CNC 6-Sided drilling machine ND510S

Name: CNC 6-Sided drilling machine ND510S
Brand: Nanxing
SKU: ND510S
Price: 3025000.0 INR
Availability: OutOfStock

₹3,025,000.00 ₹3,781,250.00

Warranty

12 Months

Country of origin

China

Specifications

Pre-installation Checklist

GST Extra

18%

Available on Request

FEATURES

• Long clamp beam & fast clamps 3.3 mtr

• Infeed air float table : 500*1613 mm

• Feed out table : 500*1613 mm

• Accurate movement of each axis X,Y,U Transported by inclined rack and pinion

• Accurate movement of Z Transported by Ball screw rod

• Servo motor for each axis

• Max travelling speed: X/U/Y/Z/V:135/135/75/30/30m/min

• Linear guiding rail and bearings can be greased automatically

• Board length detector

• Top processing unit

• Vertical drills: 10;

• Horizontal drills: 2 2 in X direction; 3 3 in Y direction. 5000rmp rotating speed,

• One 3.5kw main spindle

- TYPE:ER35

• Independent grooving saw

• Motor:1.7KW*1

• Saw blade size Dia.:100*22*4

• Bottom processing unit

Drilling block

• 9 vertical drills

• Quick change tool

• Min. processing size

• Drilling block design and software can do drilling for narrow parts

• Panel length: 200-3000mm

• Panel width 30-1000mm

• Stack processing

• Support stacking processing if hole position is mirror

• Hand controller

• Start button & pedal switch

• E-stop & Pause bar

• Industrial computer

• Windows 10 operating system.

• All-in-one industrial computer

• SYNTEC CNC control system

• Excellent electrical components

• User-friendly operation Controll interface

• Manual programming interface

• Tool management

• Simulation function

• File format support MPR, BXF, BAN, BPP, PDX, XML, XXL

• Air conditioner on control cabinet

• Safety light barrier & safety fence

TECHNICAL DATA

• Total power : 13.87 KW

• Machine size : 3962*2222*2271 mm

• Power supply : 380V/50Hz

• Air supply : 0.6-0.7MPa

• Control system Brand : SYNTEC

• Panel size Length : 200-3,000mm

• Panel size Width : 30-1,000mm

• Panel size Thickness : 10-60mm

• Max. traveling speed （X /U）axis : 135m/min

• Max. traveling speed Y axis : 75m/min

• Max. traveling speed Z axis : 30m/min

• Max. traveling speed V axis (push) : 30m/min

• Working table Material : HPL

• Working table Table size : 1232 x 275 mm

• Working table height : 955mm

• Drilling block qty : Top 1; Bottom 1

• Vert. drills qty Top : 10

• Horiz. drills qty Top : X: 6 Y: 4

• Vert. drills qty Bottom : 9

• Max drill diameter : 35mm

• Drill spacing : 32mm

• Rotation speed : 5000rpm

• Shank diameter : 10mm

• Drill length : 70mm

• Main spindle Top : 1

• Main spindle power : 3.5kw

• Dust collector qty : 2

• Dust collector diameter : Top 200mm×1

• Dust collector diameter : Bottom 125mm×1

• Dust collector speed : 28m/min

TEST

Boring Machine

CNC 6-Sided drilling machine ND510S

Multi-spindle boring precision. Every hole, every time.

QUICK SPECS

Length : 200-3

Panel Size

1232 x 275 mm

Table Size

1232 x 275 mm

Work Area

Feed Speed

13.87 KW

Total Power

13.87 KW

Power

HOW IT WORKS

Load Board

Align Stops

Drill Holes

Check Pitch

Stack Output

KEY FEATURES

— Long clamp beam & fast clamps 3.3 mtr

— Accurate movement of each axis X,Y,U Transported by inclined rack and pinion

— Accurate movement of Z Transported by Ball screw rod

— Servo motor for each axis

— Max travelling speed: X/U/Y/Z/V:135/135/75/30/30m/min

— Linear guiding rail and bearings can be greased automatically

— Board length detector

— Top processing unit

— Horizontal drills: 2+2 in X direction; 3+3 in Y direction. 5000rmp rotating speed,

— One 3.5kw main spindle

FEATURE	ADVANTAGE	BENEFIT TO YOU
SAFETY
CE-certified safety design	Meets international safety standards	You get a machine built for operator safety
Emergency stop circuit	Instant power cut-off on activation	You get immediate halt in emergencies
Enclosed moving parts	Reduces contact with rotating components	You get a safer working environment
QUALITY
Servo motor drive system	Precise, repeatable positioning	You get consistent quality across every board
USER FRIENDLY
Automatic feeding system	Hands-free panel transport	You get a single operator running the full cycle
PRODUCTIVITY
High feed speed (30)	More panels processed per hour	You get higher daily output from the same shift
Reliable cycle-time consistency	Same output rate shift after shift	You get predictable delivery schedules for customers
ROI
Reduced labour dependency	One operator can run the machine alone	You save on staffing costs and wage bills
Lower material waste	Precision cuts reduce offcut losses	You save on raw material spend every month
Durable long-life components	Extended service intervals	You save on spare parts and maintenance costs
TRUST
Authorised Nanxing Distributor	Direct factory support and genuine parts	You get the real machine with full manufacturer backing
caple.in — In business since 1974	50+ years of woodworking machinery expertise	You get advice from engineers who know the trade
12-month / 2000-hour warranty	Whichever comes first — no ambiguity	You get protected investment from day one
Trained service team	Factory-trained engineers for installation and support	You get fast, knowledgeable on-site support
Pan-India support network	Service coverage across India with multiple demo centres	You get local support wherever your factory is

TECHNICAL SPECIFICATIONS
Total power	13.87 KW
Machine size	396222222271 mm
Power supply	380V/50Hz
Air supply	0.6-0.7MPa
Control system Brand	SYNTEC
Panel size Length	200-3,000mm
Panel size Width	30-1,000mm
Panel size Thickness	10-60mm
Max. traveling speed （X /U）axis	135m/min
Max. traveling speed Y axis	75m/min
Max. traveling speed Z axis	30m/min
Max. traveling speed V axis (push)	30m/min
Working table Material	HPL
Working table Table size	1232 x 275 mm
Working table height	955mm
Drilling block qty	Top 1; Bottom 1
Vert. drills qty Top	10
Horiz. drills qty Top	X: 6 + Y: 4
Vert. drills qty Bottom	9
Max drill diameter	35mm

FREQUENTLY ASKED QUESTIONS

What is the minimum pitch between drill holes?

The standard pitch is 32 mm to match the European cabinet system. Some models support variable pitch — check the spec table above.

How many spindles does this machine have?

Refer to the spindle count in the Quick Specs section above. Multi-spindle models allow simultaneous vertical and horizontal drilling.

Can I drill both faces of a panel in one pass?

Some models support double-sided drilling. Refer to the product name and specification table to confirm this capability.

What board dimensions can the machine handle?

Refer to the panel size range listed in the Quick Specs and Technical Specifications sections above.

What is the warranty period?

12 months or 2000 operating hours, whichever comes first.

Where can I find the full manual and spare parts list for the ND510S?

Full documentation for the ND510S is available through caple.in. Contact our team or book a demo to receive the technical manual and parts catalogue.

What air pressure/CFM does the ND510S require?

The ND510S requires an air supply at 6 bar with approximately 15 CFM continuous consumption. Ensure your compressor and drier can deliver this reliably.

What is the total power consumption of the ND510S?

The ND510S draws approximately 19 HP (13.87 kW) total power. Use a 25-amp 3-phase 415V supply with separate earthing and a 20 KVA stabiliser for safe operation.

What dust extraction capacity is needed for the ND510S?

The ND510S needs approximately 2,777 CFM (4,718 CMH) dust extraction through Ø200mm × 1 + Ø125mm × 1. We recommend the Dust Collector AXC 5HP | 4500-5000 CMH.

What is the weight of the ND510S?

The ND510S weighs Not specified — contact sales. Ensure floor load capacity and proper foundation before installation.

What is under the customer’s scope?

Travel, food and stay for service engineers; material handling and lifting equipment; power tools and consumables for machine foundation; operator safety equipment; basic electrical connections up to the machine; general tool kit and measuring instruments — are all under the customer’s scope.
